EPS Sandwich Panel

The ASKIN EPS-FR Panel combines affordability,
thermal efficiency, and fire resistance in one lightweight solution. Made with a flame-retardant expanded polystyrene core and steel skins, this panel is ideal for temperature-controlled environments. Offering R-Values up to 5.85 and lengths up to 22m, it reduces energy costs and is 100% recyclable—perfect for warehouses, cool rooms, and industrial interiors.

• High R-Value up to 5.85
• Fire Rated – NCC Group 1 Compliant
• Lightweight and fast to install
• Available in 50–250mm thickness
• Fully recyclable and eco-friendly





  Thermal Performance
  Panel Thickness (mm)	U‑Value (W/m²K) at 23°C	R‑Value (m²K/W) at 23°C	R‑Value (m²K/W) at 15°C	R‑Value (m²K/W) at 0°C	R‑Value – Heat Flow Out (Winter)	R‑Value – Heat Flow In (Summer)
  50	0.86	1.15	1.20	1.30	1.40	1.40
  75	0.57	1.75	1.80	1.95	2.10	2.00
  100	0.42	2.35	2.40	2.60	2.70	2.50
  125	0.34	2.90	3.00	3.25	3.30	3.10
  150	0.28	3.50	3.65	3.95	3.90	3.70
  175	0.24	4.10	4.25	4.60	4.50	4.30
  200	0.21	4.70	4.85	5.25	5.10	4.80
  250	0.17	5.85	6.05	6.55	6.30	6.00

  Note: Total R‑Values for the building element as required by the Energy Provisions of the National Construction Code, calculated in accordance with AS/NZS 4859.2:2018. ASKIN EPS‑FR is manufactured, tested and packaged in conformance with AS/NZS 4859.1:2018. Declared Product R‑Value is calculated in accordance with AS/NZS 4859.1:2018 as required for compliance to the National Construction Code 2022.

  Note: Total R‑Values for the building element as required by the Energy Provisions of the National Construction Code, calculated in accordance with AS/NZS 4859.2:2018. ASKIN EPS‑FR is manufactured, tested and packaged in conformance with AS/NZS 4859.1:2018. Declared Product R‑Value is calculated in accordance with AS/NZS 4859.1:2018 as required for compliance to the National Construction Code 2022.




  Features & Benefits

• Flame retardant

• Fast to install

• Warranties up to 10 years

• Superior spanning capability

• Long lengths available of 22m

• Concealed Fix Systems available

• Resilient material for a changing climate


  Thermally efficient (Product R-Values up to 5.85 (23 degrees)


  Suitable for temperature controlled environments ASKIN Panel comprises an EPS-FR cellular foam core sandwiched between sheets of steel. The panel has been tested in the rigorous testing regime for surface linings prescribed in the National Construction Code (NCC). Encapsulation of the insulation material by the steel skins has been successfully proven to comply with the highest lining level of
  fire protection being NCC Group 1classification.




  Design & Installation


  Though typically installed vertically, EPS-FR panels can also be installed horizontally or diagonally to meet design requirements. The panels can be joined with top hat sections and fitted with hidden fixings including Tek screws, threaded rods, suspension brackets and more. Panel tolerance is closely controlled to support consistent and seamless installation.




  Services

  ASKIN can produce in-line services voids for special requirements.
  Please contact your ASKIN representative for further information.




  EPS Sandwich panel solution

  the ASKIN EPS-FR Panel delivers outstanding thermal insulation and NCC Group 1 fire compliance, making it ideal for cool rooms, warehouses and industrial interiors. Thanks to its lightweight steel skins, variable thickness options and lengths up to 22 m, this EPS Sandwich panel ensures rapid installation and superior spanning capability. Fully recyclable and engineered for long-term performance, that offers a cost-effective way to reduce energy costs while meeting stringent building codes.
